Use high speed blade to cut the pipe
Cut the pipe in round shape
The edges of pipe should be smooth otherwise it can be damage the Gasket while inserting in the pipe
Pipe should be inserted till the end of the fitting
Keep the fitting collar in the middle point of die.
Press the die till both face of tool join
Being effortless, Secure, and Tool-Based. Prime gold’s innovative approach to joining stainless steel water pipes and fittings eliminates the complexities of welding or threading. Utilizing hydraulic or electro-mechanical pressing tools, our process ensures swift and secure connections, enhancing both efficiency and safety. Experience a seamless installation that's durable, reliable, and completed in a fraction of the time with Primegold's revolutionary joining technique.
| Crimping range | Crimping force | Crimping type | Stroke |
|---|---|---|---|
| Cu16-43mm 2 | 16T | Hexagon crimping | 20mm |
*pipe as pre JIS 3448
| S. S 316L Grade Standard | Pipe | Fittings |
|---|---|---|
| Standard | JIS-3448 | JWWAG-116 |
| Material | Percentage (%) | Function |
|---|---|---|
| EPDM Rubber | 32.00% | |
| Filling Calcium Carbonate | 16.00% | Stabilize, avoid D-shaper of rubber |
| Reinforce (N330, N550) | 31.20% | Provide Crack Resistance |
| Softener (Paraffine Oil No - 300) | 15.20% | Avoiding Penetration due to moisture |
| Accelerator | 01.12% | Provide high physical property |
| Vulcanizer | 00.64% | Provide weather resistance and ageing resistance |
| Other | 03.84% | To give shape |
| Total | 100.00% | - |
| Material | Colour | Temprature | Function | Usage |
|---|---|---|---|---|
| Fluoronrubber | Brown | -30°C -170°C | 16 | Steam high temperature hot water |
| Filling Calcium Carbonate | Yellow | -40°C -150°C | 16 | Gas Fuel Oil |
